Deye SUN-5/6/8/10/12/15/20/25K-SG01HP3-EU-AM2 Three-Phase Hybrid Inverter Kenya

Deye SUN-5/6/8/10/12/15/20/25K-SG01HP3-EU-AM2 Three-Phase Hybrid Inverter Kenya

The Deye SUN-5/6/8/10/12/15/20/25K-SG01HP3-EU-AM2 Three-Phase Hybrid Inverter is a powerful high-voltage solar inverter series designed for residential, commercial, agricultural and industrial solar energy systems in Kenya.

Available in 5kW, 6kW, 8kW, 10kW, 12kW, 15kW, 20kW and 25kW capacities, this Deye hybrid inverter provides a flexible solution for solar generation, battery energy storage, grid power and backup applications.

The inverter supports high-voltage lithium-ion batteries from 160V to 700V, providing efficient energy storage for modern solar installations. Its high-voltage battery architecture helps reduce current and improve overall system efficiency compared with equivalent low-voltage, high-current systems.

Depending on the selected model, battery charging and discharging current reaches up to 50A, with intelligent communication between the inverter and compatible lithium battery Battery Management Systems (BMS).

The Deye SUN-5–25K-SG01HP3-EU-AM2 series features 2 independent MPPT trackers, providing flexible solar array design for panels installed on different roof orientations or under different sunlight conditions.

The series supports substantial solar PV capacity. Maximum PV access power ranges from approximately 10,000W on the 5kW model to 50,000W on the 25kW model, while maximum PV input power ranges from 8,000W to 40,000W, depending on inverter size.

A maximum PV input voltage of 1000V and a broad 150–850V MPPT operating range provide flexibility when designing high-voltage solar panel strings.

The inverter operates on 220/380V or 230/400V three-phase AC systems using a 3L + N + PE connection, making it suitable for many commercial and industrial electrical installations in Kenya.

One of its major advantages is 100% unbalanced output capability, allowing the inverter to handle different power demands across the three phases more effectively.

For backup applications, the inverter can provide off-grid peak power of up to 1.5 times its rated output for 10 seconds, helping accommodate short-duration starting loads from compatible motors and appliances.

The inverter also supports AC coupling, making it suitable for retrofitting battery storage into compatible existing solar PV installations.

For larger solar projects, up to 10 compatible Deye inverter units can be connected in parallel for on-grid or off-grid operation, while multiple compatible batteries can also be installed in parallel.

The inverter supports diesel generator energy storage, allowing compatible generator power to supply loads or recharge the battery bank as part of a properly designed hybrid power system.

Users can configure up to 6 programmable battery charging and discharging periods, helping businesses and property owners optimize solar energy, battery usage and grid consumption.

With a maximum efficiency of approximately 97.6%, European efficiency of 97.0% and MPPT efficiency above 99%, the Deye inverter is designed for efficient solar energy conversion.

An IP65-rated enclosure provides protection against dust and water, while built-in protection features include reverse-polarity protection, anti-islanding protection, thermal protection, short-circuit protection, over-current protection and Type II AC/DC surge protection.

Communication options include Wi-Fi, RS485 and CAN, with monitoring options such as GPRS, Wi-Fi, Bluetooth and 4G depending on the installed communication accessories.

The Deye SUN-5–25K Three-Phase Hybrid Inverter is ideal for large homes, farms, hotels, schools, hospitals, office buildings, warehouses, factories, apartments, shopping centres and commercial solar installations in Kenya.

For customers searching for a Deye three-phase hybrid inverter in Kenya, Deye 25kW hybrid inverter, or a high-voltage solar inverter with battery backup, the SUN-5–25K-SG01HP3-EU-AM2 series provides a powerful and scalable energy solution.

Buy the Deye SUN-5/6/8/10/12/15/20/25K-SG01HP3-EU-AM2 Three-Phase Hybrid Inverter in Kenya from Reen Power Shop for quality solar equipment, professional system sizing and installation support.
